Description
Intel Xeon X5690 SLBVX 6-core 3.46GHz CPUs with 12MB cache. High-performance LGA1366 processors for servers, workstations, and virtualization.
Upgrade your enterprise servers or high-performance workstations with this Intel Xeon X5690 processors (SLBVX). Built on Intel’s proven Westmere-EP architecture, the Xeon X5690 delivers a powerful combination of speed, reliability, and scalability for modern and legacy IT environments.
Featuring 6 cores and 12 threads, the X5690 runs at an impressive 3.46GHz base frequency, with Intel Turbo Boost Technology pushing speeds up to 3.73GHz when workloads demand extra power. With 12MB Intel Smart Cache and Hyper-Threading Technology, it handles intensive multitasking and virtualization workloads with ease.
Designed for the LGA1366 socket and compatible with Intel’s 5500/5520/5600-series chipsets, this CPU supports triple-channel DDR3 ECC Registered memory, ensuring data integrity and system stability. With dual-socket scalability (2S), the Xeon X5690 is an excellent choice for building high-density server environments or upgrading existing infrastructures.
This lot of 12 processors is ideal for system integrators, IT refurbishers, and organizations maintaining or scaling enterprise systems while maximizing cost efficiency.
Technical Specifications Table
| Specification | Details |
|---|---|
| Brand | Intel |
| Model | Xeon X5690 (SLBVX) |
| Architecture | Westmere-EP |
| Cores / Threads | 6 Cores / 12 Threads |
| Base Clock Speed | 3.46 GHz |
| Max Turbo Frequency | 3.73 GHz |
| Cache | 12MB Intel Smart Cache |
| Bus Speed (QPI) | 6.40 GT/s |
| Instruction Set | 64-bit |
| Instruction Extensions | SSE4.2, Intel 64 |
| Socket Type | LGA1366 |
| Lithography | 32nm |
| TDP (Thermal Design Power) | 130W |
| Memory Support | DDR3 ECC Registered (up to 1333 MHz, triple-channel) |
| Scalability | Dual-socket (2S) capable |
| Virtualization | Intel VT-x, Intel VT-d |
| Hyper-Threading | Yes |
| Turbo Boost | Yes |
| Product Code (S-Spec) | SLBVX |
| Warranty | Sold as-is (refer to store policy) |
Compatible Products
-
Motherboards: Intel 5500/5520/5600 chipsets (LGA1366 socket)
-
Server Platforms: Dell PowerEdge R710, HP ProLiant DL380 G7, IBM x3650 M3, Supermicro X8/X9 series
-
Memory: DDR3 ECC Registered DIMMs (1066/1333 MHz)
-
Operating Systems: Windows Server 2008/2012, VMware ESXi, RedHat Enterprise Linux, Ubuntu Server, CentOS
Ideal Use Cases
-
Enterprise server builds and upgrades
-
Virtualization and cloud hosting
-
High-performance workstations (CAD, 3D rendering)
-
Database and ERP applications
-
Small-to-medium business IT infrastructures
-
Legacy system upgrades for data centers
Key Features / Highlights
-
Intel Xeon X5690 processors (SLBVX)
-
6 cores / 12 threads with Hyper-Threading Technology
-
3.46GHz base / 3.73GHz turbo boost speeds
-
12MB Smart Cache for faster data handling
-
Compatible with LGA1366 motherboards (Intel 5500/5520/5600)
-
Supports DDR3 ECC Registered Memory for stability
-
Dual-socket capable for scalable performance
-
Ideal for servers, virtualization, and high-performance workstations
Comparison Angle
The Xeon X5690 represents one of the highest-performing CPUs in the Xeon 5600-series lineup, offering higher clock speeds, larger cache, and better power efficiency compared to earlier Xeon X5500 processors. It improves significantly over the X5670 and X5680 with faster per-core performance, making it a strong choice for workloads requiring both speed and reliability.
Cross-Sell / Upsell Suggestions
-
DDR3 ECC Registered Memory Kits (4GB / 8GB / 16GB modules)
-
Dual-socket LGA1366 motherboards (Intel 5520/5600 chipset)
-
Enterprise rackmount servers (Dell R710, HP DL380 G7, Supermicro barebones)
-
Server cooling solutions compatible with LGA1366 CPUs
-
RAID controllers & enterprise SSDs for performance boosts
-
Redundant power supplies for high-availability setups
