Description
Boost SAN performance with the IBM 2498-B24 Fibre Channel Switch. 24x 8Gb FC ports, rackmount design, enterprise-grade scalability & reliable storage networking.
Product Features
-
24 Fibre Channel ports delivering 8Gbps high-speed connectivity
-
Rackmount 1U design for efficient data center integration
-
Ideal for SAN storage networks, servers, and enterprise infrastructure
-
Scalable architecture to grow with expanding storage demands
-
Supports zoning, trunking, and advanced FC management features
-
Non-blocking architecture for consistent low-latency performance
-
Compatible with IBM System Storage, EMC, NetApp, HP, Dell storage arrays
-
Enterprise-grade reliability, redundancy, and power efficiency
General Product Information
The IBM 2498-B24 SAN Fibre Channel Switch is designed for enterprise-class storage networking, offering powerful 24-port 8Gb Fibre Channel connectivity in a compact rackmount 1U form factor. Built for mission-critical environments, it provides low-latency, non-blocking performance that ensures your servers and storage arrays communicate seamlessly without bottlenecks.
With 8Gbps per port throughput, the IBM 2498-B24 supports virtualization, backup, disaster recovery, and data-intensive workloads across enterprise environments. Its advanced zoning, trunking, and intelligent fabric management enhance data traffic flow and provide maximum network security and flexibility.
Compatible with leading storage systems—including IBM System Storage, EMC, NetApp, HP, and Dell arrays—this switch enables seamless integration into existing SAN infrastructures. Its scalable design allows organizations to expand storage connectivity as data demands grow, while maintaining predictable and reliable performance.
Whether for data centers, enterprise backup, or high-performance computing environments, the IBM 2498-B24 delivers the speed, scalability, and resilience modern businesses need.
Technical Specifications Table
| Specification | Details |
|---|---|
| Model | IBM 2498-B24 |
| Product Type | SAN Fibre Channel Switch |
| Ports | 24x 8Gb Fibre Channel |
| Throughput | Up to 8Gbps per port |
| Architecture | Non-blocking, low-latency switching |
| Scalability | Supports ISLs (Inter-Switch Links), trunking |
| Form Factor | 1U Rackmount |
| Dimensions (HxWxD) | ~1.75” x 17” x 18” |
| Weight | ~18 lbs |
| Management | Web-based GUI, CLI, SNMP, advanced zoning features |
| Power Supply | Redundant hot-swappable |
| Operating Temp | 10°C–40°C (50°F–104°F) |
Compatible Products
-
IBM System Storage DS, V7000, XIV, FlashSystem arrays
-
EMC, NetApp, Dell, HP storage systems
-
IBM Power Systems, xSeries servers, BladeCenter platforms
-
VMware, Hyper-V, Linux, and Windows Server environments
-
Fibre Channel HBAs (Emulex, QLogic, Broadcom)
Ideal Use Cases
-
Data centers – scalable SAN fabric backbone
-
Enterprise storage networks – fast, reliable Fibre Channel switching
-
Virtualization environments – VMware, Hyper-V, KVM workloads
-
Backup & disaster recovery – efficient data replication across sites
-
High-performance computing (HPC) – low-latency, high-throughput SAN
Comparison Angle
Compared to earlier 4Gb Fibre Channel switches, the IBM 2498-B24 doubles bandwidth to 8Gbps per port, delivering faster data transfers and improved scalability. Its non-blocking architecture and redundant power design ensure better reliability than competing mid-range SAN switches, while maintaining lower latency for virtualization and high-demand workloads.
