Description
Dell P570F 2U rackmount server chassis with NVMe support, dual 1600W PSUs, BOSS adapter, H330+ HBA & 25Gb dual-port NIC. Flexible, enterprise-ready.
| specifications | Details |
|---|---|
| Model | Dell P570F |
| Form Factor | 2U Rackmount |
| CPU | Not Installed / N/A |
| Memory | Not Installed / N/A |
| Primary Storage | Not Installed / N/A |
| Boot Storage | BOSS Adapter with 2 × 240GB M.2 SSDs (P/N: 07HYY4) |
| Networking | 25Gb Dual-Port NIC Daughter Card (P/N: 06WMMV) |
| RAID / HBA | Dell H330+ 12Gb/s HBA (P/N: 0J7TNV) NVMe SSD Controller (P/N: 0235NK) |
| Expansion / Riser Cards | 3 × PCIe Riser Cards (P/Ns: 0J7W3K, 0GHGTP, 0DTTHJ) |
| Other Components | Dual SD Card Reader (P/N: 0RT6JG), 2 × Heatsinks |
| Power Supply | 2 × 1600W Redundant Hot-Plug PSUs (P/N: 095HR5) |
Product Features
-
Enterprise-grade Dell P570F 2U rackmount server chassis.
-
Pre-installed BOSS adapter with 2 × 240GB M.2 SSDs for secure OS boot.
-
Includes Dell H330+ 12Gb/s HBA for storage expansion.
-
NVMe SSD controller for high-speed flash storage.
-
Networking-ready with 25Gb dual-port NIC daughter card.
-
3 × PCIe riser cards included for flexible expansion.
-
Dual 1600W redundant power supplies for reliability.
-
Barebones server chassis – CPU, memory, and primary storage not included.
General Product Information
The Dell P570F High-End 2U Server Chassis is designed for enterprises that require flexible expansion, high-speed NVMe support, and redundant power for mission-critical workloads.
This configuration comes equipped with a BOSS adapter featuring 2 × 240GB M.2 SSDs, ensuring secure and reliable OS boot. For storage flexibility, it includes a Dell H330+ 12Gb/s HBA and a dedicated NVMe SSD controller, enabling deployment of both traditional HDD arrays and ultra-fast NVMe drives.
Networking is powered by a 25Gb dual-port NIC daughter card, delivering robust bandwidth for virtualization, HPC, or cloud environments. With 3 PCIe riser cards included, this chassis offers significant expansion options for additional RAID cards, NICs, or GPUs.
The chassis is powered by dual hot-plug 1600W redundant PSUs, ensuring enterprise reliability and uptime. While this system ships without CPUs, RAM, or primary storage, it’s fully customizable to meet the needs of data centers, cloud deployments, and enterprise IT environments.
Technical Specifications Table
| Category | Details |
|---|---|
| Brand | Dell |
| Model | PowerEdge P570F |
| Form Factor | 2U Rackmount |
| CPU | Not included (compatible with Intel Xeon Scalable processors, varies by config) |
| Memory | Not included (supports DDR4 ECC Registered DIMMs) |
| Boot Storage | Dell BOSS Adapter with 2 × 240GB M.2 SSDs |
| Storage Controller | Dell H330+ 12Gb/s HBA NVMe SSD Controller |
| Networking | 25Gb Dual-Port NIC Daughter Card |
| Expansion | 3 × PCIe Riser Cards |
| Other Components | Dual SD Card Reader, 2 × Heatsinks |
| Power Supply | 2 × 1600W Redundant PSUs |
| Cooling | Integrated hot-swappable fans |
| OS Compatibility | Windows Server, VMware ESXi, Linux (RHEL, Ubuntu, CentOS) |
Compatible Products
-
Dell PowerEdge CPU & memory upgrade kits (Xeon Scalable processors, DDR4 RAM).
-
Dell PowerEdge compatible storage (SAS, SATA, NVMe SSDs).
-
VMware ESXi, Microsoft Hyper-V, Linux enterprise OS.
-
Dell rack rails & caddies for deployment.
-
Dell RAID controllers & advanced NICs.
Ideal Use Cases
-
Enterprise data centers requiring NVMe-ready servers.
-
Virtualization & cloud infrastructure.
-
High-performance computing (HPC) workloads.
-
Database hosting and analytics.
-
Business continuity & disaster recovery setups.
Comparison Angle
Compared to older Dell 2U rackmount servers, the P570F delivers higher network bandwidth (25GbE), NVMe-ready storage expansion, and redundant 1600W PSUs, making it ideal for next-generation enterprise deployments. Unlike entry-level servers, this system is designed for high uptime, modular expansion, and flexible workloads.
